Round Cast Iron Manhole Cover, Sand Cast Iron Manhole Cover

Round cast iron manhole cover, sand cast iron manhole cover

Round manhole coverSpecial Round manhole coverArticle No.Dimensions/mmHeight/mmweight/kgRemarksArticle No.Art.nameDimensions/mmHeight/mmweight/kgRemarks1580*6504015 square manhole cover400*4004014 2580*6505022 500*5003515 1600*7003518 5000*5005025 A680*7803523 600*600352

Round manhole cover					Special Round manhole cover
Article No.	Dimensions/mm	Height/mm	weight/kg	Remarks	Article No.	Art.name	Dimensions/mm	Height/mm	weight/kg	Remarks
1	580*650	40	15			square manhole cover	400*400	40	14
2	580*650	50	22				500*500	35	15
1	600*700	35	18				5000*500	50	25
A	680*780	35	23				600*600	35	22
B	680*780	50	27				600*600	50	35
C	680*780	65	34			Outer inner circle	700*780	50	40
1	700*800	50	25
2	700*800	60	34			Outer inner circle (double-deck)	900*1000	100	80
3	700*800	60	39			Outer inner circle (double-deck)	900*1000	100	135
3S	700*800	60	43	octagon		double-deck	680*870 cruciate flower	70	43
4	700*800	70	45	octagon		double-deck	680*870 cruciate flower	70	43
5	700*800	70	48			double-deck	700*900	100	78
5	700*800	70	48			double-deck
6	700*850	80	53	octagon		double-deck	flower design
7	700*850	80	58	octagon		double-deck	900*1000	100	85
8	700*850	80	58			double-deck	900*1000	190	70
9	700*850	80	68	octagon	A	Prevention of settlement	700*900	190	80
10	700*880	100	70		B	Prevention of settlement	700*900	190	95
11	700*880	100	75	Leaflet	C	Prevention of settlement	700*900
12	700*880	100	85	Leaflet
13	700*880	100	88			can be locked
1	800*900	35	38
2	800*900		45
	800*900	80	70

Material: Ductile Iron GGG500-7/450-10
Designs :EN124 A15, B125, C250, D400, E600 and F900
Coating : Cold applied black bitumen ; Without coating ; Coating as per customers' requirement
Round Iron Casting Manhole Cover, Sand Iron Casting Manhole Cover

Round Iron Casting Manhole Cover, Sand Iron Casting Manhole Cover

Answer Quickly And Offer Very Attractive Price

Products Are Exported To Eur, Ru, Th, Mas, And Many Other Countries

100% Payment Protection
